433MHz Rolling Code Wireless Wiegand Access Control 30m Wireless Distance RFID Card Reader 125KHz EM Wireless Card Reader433MHz Rolling Code Wireless Wiegand Access Control 30m Wireless Distance RFID Card Reader 125KHz EM Wireless Card Reader433MHz Rolling Code Wireless Wiegand Access Control 30m Wireless Distance RFID Card Reader 125KHz EM Wireless Card Reader433MHz Rolling Code Wireless Wiegand Access Control 30m Wireless Distance RFID Card Reader 125KHz EM Wireless Card Reader

433MHz Rolling Code Wireless Wiegand Access Control 30m Wireless Distance RFID Card Reader 125KHz EM Wireless Card Reader

  • Model: ACM301

433MHz Rolling Code Wireless Wiegand Access Control 30m Wireless Distance RFID Card Reader 125KHz EM Wireless Card Reader

Wireless reader

> 433 MHz Rolling Code technology
> Card type: 125KHz EM card or 13.56MHz MF card
> Programmable Wiegand output of the receiver: 26 bit or 34 bit
> Communication distance: maximum 30m
> Extremely low energy consumption
> Waterproof, IP65 compliant

Product parameter Parameter description
Template ACM301
product name Wireless Wiegand reader
Wireless keyboard reader
Kind of paper EM 125KHz card
Operating voltage 3 units of AAA batteries
Idle current ≤5uA
Working current ≤35mA
Reading distance ≤3 cm
Communication frequency 433 MHz
Communication distance 30 m maximum
operating temperature -20 ° C~+ 60 ° C (-4 ° F~+ 140 ° F)
Operating humidity 0%~86%
Protection index IP65
Color Black, white optional
Dimensions L120 * W50 * H20 (mm)
Net weight 88g
Receiver
Operating voltage 12V DC
Working current ≤15mA
Communication frequency 433 MHz
Wiegand output format 26 bit or 34 bit (default is 26 bit)
operating temperature -20 ° C~+ 60 ° C (-4 ° F~+ 140 ° F)
Operating humidity 0%~86%
Dimensions L25 * W50 (mm)
Net weight 10g

433MHz Rolling Code Wireless Wiegand Access Control RFID Card Reader with 30m Wireless Distance 125KHz EM Wireless Card Reader

433MHz Rolling Code Wireless Wiegand Access Control RFID Card Reader with 30m Wireless Distance 125KHz EM Wireless Card Reader433MHz Rolling Code Wireless Wiegand Access Control RFID Card Reader with 30m Wireless Distance 125KHz EM Wireless Card Reader433MHz Rolling Code Wireless Wiegand Access Control RFID Card Reader with 30m Wireless Distance 125KHz EM Wireless Card Reader
