RS485 RJ45 8-15M long range 8dbi Antenna RS232 Wiegand parking management system UHF RFID reader
Place of Origin: Guangdong, China
Brand Name: ACM
Frequency: 860-960mhz
Protocol: ISO 18000-6C
Item name: parking management system UHF RFID reader
Interface: TCP/IP, USB, WIFI, wrigand for chiose
Read Distance: 15m
Antenna: 8dbi
Read Speed: 100tags/s
RF Power: 30dBm(adjustable)
Write Distance: 7m
Power Supply: 12V DC
Keyword: Uhf Fixed Reader
Material: ABS Plastic
Product Description
OVERVIEW
811A is a high-performance UHF RFID integrated reader. It is designed with low power dissipation and high integrated RFID chip solution, which has features of long reading distance, high identification speed, multiple interfaces and ease installation. It can be widely used in logistics tracking, commodity inventory, cargo sorting, vehicle management, personnel management, asset management, medical systems, cold chain management, temperature monitoring, power monitoring, anti-counterfeiting systems and production process control and many other applications.
Key Features
* Designed with low power dissipation and high integrated RFID chip solution
* Support EU 840~868MHz, US 902~928MHz working frequency (or Customized)
* Support EPC Global UHF class 1 gen2 / ISO18000-6C protocol RFID tags.
* Optimized multiple tags inventory algorithm, speed is more than 100 per second
* FHSS or Fix Frequency transmission
* RF output power up to 30dBm (1dbm step adjustable)
* Support command, polling and trigger mode
* Support EPC, TID and USER inventory in independently or conjunctively
* Support IAP firmware upgrading
* Low power dissipation with single +12 DC power supply
* Support USB, RS232, RS485, Weigand, RJ45(TCP/IP, UDP) and WIFI, 4G at option
* Built-in 8 dBi circular polarized antenna with effective distance up to 20 m (adjustable)
* Provide DEMO and SDK for development
* Support development based on Windows, Android, Linux etc. and C, C#, JAVA etc.
EU 840~868MHz/ US 902~928MHz or customized
Fixed or FHSS
RF Power
30dBm±1dB(Max)
Step Power
30dBm±1dB(Max)
Step Power
1dBm
Signal Width
<250KHz
Antenna
Built-in 8dBi circular polarized antenna
Tag Reading
Effective Distance
8dBi circular polarized antenna, 30dBm, standard testing tag
Read:8m
Write:3 meters
Reading Speed
100tags/s
Communication Parameter
Interface
RS232, RS485, Weigand 26/34, Trigger and RJ45(TCP/IP, UDP, PoE)
4G, BT and WIFI are optional
Baud Rate
115200bps
Power Parameter
Operating Voltage
+12.0V(+9~+24V)
Operating Current
<600mA/DC12V
Standby Current
<200mA/DC12V
Temperature Parameter
Operating Temperature
-20~+55°C
Storage Temperature
-30~+85°C
Operating Humidity
<95%RH (+25°C) Non-condensing
Product Picture
Product Picture
Related Products
Detailed Images
RFID UHF 15m long range card reader can be compatible with mult-protocol, integrated design,multi-tag reading, anti-collision, suitable for logistic and warehouse management, car parking system, access control, time attendance, bus transportation etc lots of field, can read and write , fast speed read and recognized.This is a popular integrated reader, Compatible with ISO18000-6C (EPC C1GEN2) and ISO18000-6B.It is an industry grade product for harsh environment, IP-65 protection case for water-proof, easy to install.Mainly application as follows:1. Parking management: Long range intelligent parking management and automatic charge without stop the car.2. Production line management: Goods identification for production flow.3. Auto Access control: Long range access control management for custom, sea port.4. Logistics and warehouse management.5. People auto registry for important meeting or exhibition.6. Automatic weighing and data capture.Features: Support ISO18000-6C and ISO18000-6B protocol.? RS232, RS485, Wiegand26/34, RJ45 communication interface support. Advanced tag collision processing algorithm, high literacy rate. High-Speed write data.
