High Identifiction Rate Adjust Distance 3-70m Wiegand 26bit Reader Long Range RFID 2.4G Active ReaderHigh Identifiction Rate Adjust Distance 3-70m Wiegand 26bit Reader Long Range RFID 2.4G Active ReaderHigh Identifiction Rate Adjust Distance 3-70m Wiegand 26bit Reader Long Range RFID 2.4G Active ReaderHigh Identifiction Rate Adjust Distance 3-70m Wiegand 26bit Reader Long Range RFID 2.4G Active Reader

High Identifiction Rate Adjust Distance 3-70m Wiegand 26bit Reader Long Range RFID 2.4G Active Reader

  • Product Name:Wiegand 26bit Reader Long Range RFID 2.4G Active Reader
  • Operation Mode:Fixed Frequency or FHSS or Software Programmable
  • RF Power Output Adjustable:Power Output Adjustable Range:0.1W --- 1W
  • Built- in Antenna Type:Built-in Circularly polarized antenna.
  • Communication Rates:Up to 57,600bps and software programmable
  • Power Consumed:DC-9V±0.5V Adapter, less than 3 Amps
  • Operation Temp:Working Temp.:-35°~ +60 ° Storage Temp.:-50°~ +80°
  • Interface:Wiegand
  • Reading Distance:adjust distance:3~70m
Product Description

High Identification Rate Adjust Distance 3-70m Wiegand 26bit Reader Long Range RFID 2.4G Active Reader

ACM08G RFID 2.45GHz Long Range Active Directional Card Reader, Widely used for car parking long range automated system 1)Operation frequency: ISM2.45GHz 2)Reading range: adjust distance: 3~80meter

Specification of 2.4GHZ Active Reader

Product Parameter
Power Consumed
Model
ACM09G 2.4GHZ active reader
Frequency
2.4GHZ
Operation Mode
Fixed Frequency or FHSS or Software Programmable
RF Power Output
0~30dBm
Built- in Antenna Type
Built-in Circularly polarized antenna.
Reading Rate
Software Programmable,Average Reading per 64Bits:<10ms
Reading Mode
Auto And Touch or Software Programmable
Communication Ports
RS232 /485 , wiegand 26/34
Data Input
Input One Team
Reading Range
3-80M
Reading Clue
Buzzer
Antenna
Built-in Antenna,Gain:7dbi
Power Consumed
DC +9v AC–DC Adapter, less than 3 Amps
Detailed Images
