User Capacity
Common User
Visitor User
Panic User
|
Hardware User: 1000 APP User: 500
988 PIN/Card Users)
10
2
|
|
PIN Length
|
4~6 digits
|
|
Operating Voltage
Idle Current
Active Current
|
12~18V DC
≤ 60mA
≤ 150mA
|
|
Proximity Card Reader
Radio Technlogy
Read Range
|
EM
125KHz
2~6cm
|
|
Wiring Connections
|
Relay output, exit button, alarm, door contact, Wiegand input/output
|
|
Relay
Adjustable Relay Output Time
Lock Output Load
|
One (NO, NC, Common)
0~99 Seconds (5 seconds default)
2 Amp Maximum
|
|
Wiegand Interface
PIN Output
|
Wiegand 26~44 bits input & output (Factory default: Wiegand 26bits)
4 bits,8bits (ASCII),10 digits Virtual Number(Factory default:4bits)
|
|
Environment
Operating Temperature
Operating Humidity
|
Meets IP66
-40°C ~ 60°C (-40°F ~ 140°F)
0%RH ~ 98%RH
|
|
Physical
Color
Dimensions
Unit Weight
Shipping Weight
|
Zinc-Alloy
Sliver & Black
L150 x W45 x H22 (mm)
190g
280g
|
