factory wiegand 26 34 13.56mhz rfid reader rfid smart card nfc card access control reader

Place of Origin:Guangdong, China
Brand Name:ACM
Power Supply:DC 12V(±5%)
Current:55mA
Frequency:13.56Mhz
Type:RFID card reader
Interface:Wiegand 26 /Wiegand 34 (Setting by yourself)
Size:86*86*23(mm)
Read range:Card:30--100mm , Keychain:30-40mm
Support Cards:MF S50, S70, Ultralight, F08 etc
Weight:about 150G
Service Temperature:-10℃~+60℃

Product description

Parameter List

Item	Parameters
Power Supply	DC 12V(±5%)
Consumed Current	≤50mA(standby ) ≤60mA(Work)
Support Cards	MF S50, S70, F08 tags comply with ISO14443A protocal etc
Reading Distance	Card:30--100mm , Keychain:30-40mm
Reader Time	<200ms
Format	Wiegand 26 & Wiegand 34 (Setting by yourself)
Distance of transmission	100M
Service Temperature	-10℃~+60℃
Size	86mm86mm23mm
N.W.	About 150G
Status Indication	1PC LED (Blue means standby, Green means reader success)

Line definition

Color	Parameter
Red	VCC(12V)
Green	Wiegand D0
Black	GND
White	Wiegand D1
Purple	Wiegand 26/Wiegand 34 (The output format is WG34 when purple line connect with black line)
Grey	Green light and buzzer long ring

Application

R352M RFID card reader,widely used to data input,information search,book-lending,meeting signature,access control etc.

Shenzhen factory wiegand 26/34 13.56mhz rfid reader , rfid smart card,nfc card access control reader
