Metal IP66 Waterproof Standalone Bluetooth Access Control
ACM-218G Bluetooth
Standalone Bluetooth Access Control
> Metal case, vandal-proof
> Waterproof, IP66 compliant
> One relay (Pulse mode, toggle mode)
> 10000 users (mobile phone users + card users)
> 2 ways to open the door: mobile phone and cards
> Compatible with all Bluetooth-enabled mobile phones (version: 4.0 above)
> APP supports Android 4.3 and IOS7.0 above
> Support sending remote electronic key to users: admin can control the access time
Product parameter | Parameter description |
Template | ACM-218G-Bluetooth |
product name | Access control keypad in metal and waterproof |
User capability | 10000 |
Paper |
13.56 MHz Mifare card (S5-BT MF) / 125 KHz EM Card (S5-BT EM) |
Mobile | Android 4.3 and IOS7.0 above |
Operating voltage | 12V DC |
Current at minimum | <35mA |
Active current | <90mA |
Proximity card reader | Mifare card / EM card |
Radio technology | 13.56 MHz / 125 KHz |
Card reading interval | 2~ 6 cm |
Bluetooth | Bluetooth version: 4.0 above |
Range | <20m (related to the environment) |
Reaction | <2 seconds |
Relay | One (NO, NC, common) |
Output load lock | 2 Amp maximum |
Environment | Meets IP66 |
operating temperature | -20° C ~ + 60 ° C |
Operating humidity | 0%~ 98% |
Physical | Zinc alloy housing |
Dimension | L103 x W48 x H19 (mm) |
Unit of weight | 0.27 kg |
Standard package | 40 pieces / carton |
Carton weight | 10.8 kg |
Carton size | 47 * 30 * 18.2cm |
We are professional access control manufacturer, we have complete product access control system as follows:
RFID touch keypad and keypad access control, EM 125/4000 US 125Khz capacity
Keypad Access control to a metal door RFID (not waterproof), 125Khz EM
RFID reader with single watertight door and access control
Access control with single RFID metal door (not waterproof)
Access control RFID touch control, 125Khz EM, can connect wiegand reader
Touch keypad Metal case Waterproof RFID access control, can connect wiegand reader
1, All questions will be answered within 24 hours
2, professional manufacturer and supplier, welcome to visit our website and factory
3, OEM / ODM available
4, high quality, fashin design, reasonable and competitive price, fast delivery time
5, after-sales service:
1), all products will have been strictly home checked before packing
2), all products will be well packed before shipping
3), All of our products have 2-3 years warranty if the damage is not caused by human being
6, faster delivery : About 1 ~ 5 days for sample order, 7 ~ 30 days for bulk order
7, payment: You can pay for the order by: T / T, Western Union, Paypal, Ali trade insurance
8, Shipping: We have strong partnership with DHL, FEDEX, TNT, UPS, EMS, sea and air freight forwarder, you can also choose your own freight forwarder.
Q: 1. How can I place an order?
A: List your needs by email. Then we will send you the offer as soon as possible, after your order is confirmed, we will arrange the production as soon as possible.
Q: 2. What about payment and shipping?
A: Trade assurance and T / T, Paypal, Western Union.
Customers can choose by sea, air or express (DHL, FedEx, TNT UPS etc.)
Q: 3. How can I get a sample to check the quality?
A: We could provide you with free sample and the freight cost paid by you.
Q: 4. How long can I wait to get the samples?
A: It depends on the quantity. Normally 3-7 days for 5000 pieces and 7-15 days for 100,000 pieces
Q: 5. Can your products be customized?
A: Almost all of your products are customized, including material, size, thickness and printing.OEM orders are welcome.
Q: 6. Are you a trading company or a factory?
We are one of the leading manufacturers of RFID card / NFC tag / RFID keybod / RFID reader RFID reader and access control products in China for over 20 years.
