1: Strong Zinc Alloy Electroplated anti-vandal case
2: Full programming from the keypad
3: 2000 uses, supports Card, PIN, Card + PIN
4: Backlight keys
5: Red, Yellow and Green LEDS display the working status
![]()
![]()
![]()
![]()
![]()
|
Card type |
EM / MF |
|
Waterproof degree |
IP68 |
|
Operating Voltage |
DC 12V±10% |
|
User Capacity |
2000 |
|
Card Reading Distance |
|
|
Active Current |
<60mA |
|
Idle Current |
25±5 mA |
|
Lock Output Load |
Max 3A |
|
Alarm Output Load |
Max 20A |
|
Operating Temperature |
-45℃~60℃ |
|
Operating Humidity |
10%- 90% RH |
|
Waterproof |
Conforms to IP68 |
|
Adjustable Door Relay time |
0 -99 seconds |
|
Adjustable Alarm Time |
0- 3 minutes |
|
Wiegand Interface |
Wiegand 26 bit |
|
Wiring Connections |
Electric Lock, Exit Button, External Alarm,External reade |
