ACM09G-WEG26/ ACM09G-TCP/IP High quality  Active rfid reader long range readerACM09G-WEG26/ ACM09G-TCP/IP High quality  Active rfid reader long range readerACM09G-WEG26/ ACM09G-TCP/IP High quality  Active rfid reader long range readerACM09G-WEG26/ ACM09G-TCP/IP High quality  Active rfid reader long range reader

ACM09G-WEG26/ ACM09G-TCP/IP High quality Active rfid reader long range reader

  • Model Number: ACM09G-WEG26/ ACM09G-TCP/IP
  • Product Name: Active rfid reader long range UHF Rfid Reader for car packing system
  • Frequency: 2.4GHZ
  • Operation Mode: Fixed Frequency or FHSS or Software Programmable
  • RF Power Output Adjustable: Power Output Adjustable Range:0.1W --- 1W
  • Built- in Antenna Type: Built-in Circularly polarized antenna.
  • Communication Ports: RS-232 ,Weigand 26 bits \ 32bits
  • Communication Rates: Up to 57,600bps and software programmable
  • Power Consumed: DC-9V±0.5V Adapter, less than 3 Amps
  • Operation Temp: Working Temp.:-35°~ +60 ° Storage Temp.:-50°~ +80°
Product Description

Active rfid reader long range UHF Rfid Reader for car packing automated system

ACM09G RFID 2.45GHz Long Range Active Directional Card Reader, Widely used for car parking long range automated system 1)Operation frequency: ISM2.45GHz 2)Reading range: adjust distance: 3~80meter

Specification of 2.4GHZ Active Reader

Product Parameter
Power Consumed
Model
ACM09G 2.4GHZ active reader
Frequency
2.4GHZ
Operation Mode
Fixed Frequency or FHSS or Software Programmable
RF Power Output
0~30dBm
Built- in Antenna Type
Built-in Circularly polarized antenna.
Reading Rate
Software Programmable,Average Reading per 64Bits:<10ms
Reading Mode
Auto And Touch or Software Programmable
Communication Ports
RS232 /485 , wiegand 26/34
Data Input
Input One Team
Reading Range
3-80M
Reading Clue
Buzzer
Antenna
Built-in Antenna,Gain:7dbi
Power Consumed
DC +9v AC–DC Adapter, less than 3 Amps
Detailed Images
Packing & Delivery

Shipping Way

We are one of the leading exporter of RFID products in China since 2000 years . With rich international trade experience we know the international shipping very well , We know which express or air/sea line is cheap and safe to your country . We can supply various certificate for you to clean your custom to such as CO , FTA , Form F , Form E ...Ect . We wil provide our professional suggestion for your shipping . EXW , FOB , FCT , CIF , CFR ...trade term are ok for us . We can be your reliable partner for products and shipping .

Your May Need

  We are Professional uhf reader manufacturer , Except the ACM812A , we also can supply ACM802A , ACM818A , ACM801A . The main difference of them are the reading distance . Also , ACM801A can be used to read multi-tag(200 pcs at one time ) . For more detail , please click following picture .




ACM812A
2-5m reading range UHF reader
Wiegand 26 output, RS232/485



ACM818A
10-20m long range UHF reader
Wiegand 26 output, RS232/485



ACM802A
8-10m reading range UHF reader
Wiegand 26 output, RS232/485




ACM801A
10-15m UHF reader
Wiegand 26 output, RS232/485



ACM 8017
UHF Handheld Reader
UHF+WIFI+GRPS



ACM 918K
UHF 4-Antenna Channel High Performance Fixed Reader
