User Capacity
Common Users
Visitor Users
Panic User
|
1000
988 (100 FP+888 Card/PIN users)
10
2
|
|
Operating Voltage
Idle Current
Active Current
|
12~28V AC/DC
≤150mA
≤60mA
|
|
Proximity Card Reader
Radio Technology
Read Range
|
EM or Mifare
125KHz / 13.56MHz
2~6 cm
|
|
PIN Length
|
4~6 digits
|
|
Wiring Connections
|
Relay output, exit button, Alarm, Door Contact, Wiegand In & Out
|
|
Relay
Adjustable Relay Output Time
Lock Output Load
|
One (NO, NC, Common)
0~99 Seconds (5 seconds default)
2 Amp Maximum
|
|
Wiegand Interface
PIN Output
|
EM Card: Wiegand 26~44 bits In & Out (26 bits in default)
Mifare Card: Wiegand 26~44, 56 ,58 bit In & Out (34 bits in default)
4bits, 8bits(ASCII), 10 digits Virtual Number (4 bits in default)
|
|
Environment
Operating Temperature
Operating Humidity
|
Meets IP66
-30°C ~ 60°C (-22°F ~ 140°F)
0%RH ~ 98%RH
|
|
Physical
Colour
|
Zinc-Alloy
Silver
|
|
Dimensions
Unit Weight/Shipping Weight
|
L150 x W70 x H21 (cm)
330g/405g
|
